PMC 8-2 SUB

The PMC8-2 SUB is a larger subwoofer for full-bandwidth, high-resolution reference monitoring in the most demanding professional environments.

The PMC 8-2 SUB is a true low-frequency monitor like the PMC8 SUB and offering the same DSP engine and seamless integration with surround and immersive systems, the PMC8-2 SUB betters the spec of its smaller sibling, offering higher maximum SPL output down to 25Hz.

With the same dimensions as the PMC8-2 midfield monitor, the PMC8-2 SUB’s twin eight-inch bass drivers are powered by independent 400W Class-D amplifiers. The same configuration options are available as on the PMC8 SUB, likewise accessible on the speaker’s rear panel or by using the browser-based SoundAlign™ software via a LAN-connected tablet, smartphone or computer.

The PMC8-2 SUB can be used as a standalone subwoofer for multichannel and immersive sound systems, or as an XBD cabinet with either PMC6-2 or PMC8-2 s, creating a system of awesome power and dynamic range. The sub is available in either left- or right-handed cabinet versions (PMC8-2 SUB-L or PMC8-2 SUB-R), to allow placement of the bass drivers on the outside edges of a stereo array, matching the arrangement of the main monitors.

PMC 8-2 SUB

£0.00 £5,100.00 inc. VAT

£4,250.00 exc. VAT

PMC 8-2 SUB

QTY:

ADD TO YOUR WISHLIST

Active subwoofer with twin 8-inch bass drivers and ATL™ bass loading
Frequency response: 25Hz - 500Hz (- 3dB) (@1m full space, on-axis)
Max. cont. SPL: 115dB @1m (quarter space value calculated as +3dB from half space measurement.
Unweighted input,20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)
State-of-the-art Class-D amplifier: 2 x 400W
Analogue/AES3 digital input (16/24-bit, 18 -192kHz sample rate)
Digital ‘through’ output (AES3 24-bit, 96kHz)
SoundAlign™ network control interface for single or group EQ & settings
Sophisticated DSP driver protection, EQ, and delay/phase options
Dedicated XBD configuration mode

TypeActive subwoofer with twin 8-inch bass drivers and ATL™ bass loading

Drive Unit ComplementLF PMC 200mm (8”) studio 8 driver

Effective ATL™ Length3m (9.8ft)

Frequency Response25Hz - 500Hz (- 3dB) (@1m full space, on-axis)

Sensitivity

+4dBu input signal = 98dB SPL @1m

Max continuous SPL115dB @1m (Quarter space value calculated as +3dB from half space measurement. Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)

Max Peak SPL121dB @1m (Quarter space value calculated as +3dB from half space measurement. Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)

InputXLR switchable between analogue & digital AES3 Analogue input- +20/+24dBu max. input level (selectable) - 22K ohm input impedance Digital input- 16/24-bit AES3 signal, left, right or left + right - 18 - 192kHz Sample Rate - 110 ohm input impedance Expansion card slot- For future connectivity upgrades

OutputXLR digital AES3 (fixed 24-bit @ 96kHz)

NetworkRJ45 for use with PMC SoundAlign web interface

FeaturesLevel Trim (+/-10dB) High-pass/Low-pass filter (20 - 200Hz, 12dB/Oct) Delay (0 - 30mS) Phase (normal or inverted) LF & HF shelving filters (20Hz - 20kHz, +/- 10dB, Q 0.707) Parametric EQ (5 bands, 20Hz - 20kHz, +/- 10dB) User presets (3 + factory defaults)

Latency2.4mS

Amplifier power per channel300Wrms

Mains100 - 240VAC auto-switching, 50-60Hz (IEC C14)

Power consumption (idle)25W

Power consumption (max)300W

Cabinet dimensionsH 534mm (21”)) W 551mm (21.7”) D 440mm (17.3”)

Weight37.5kg (82.7lbs) each

Available Finishes: Studio black
