Shadow Hills Oculus Monitor Console

SHADOCULUS
POA
ENQUIRE

Monitor console with internal PSU and wireless Remote Pendant

Shadow Hills Industries has done it again! The Oculus monitor controller is a striking centerpiece to your studio control room, providing crucial functionality and performing to top-notch specifications. Monitor reference level control, talkback, autocue, Class A headphone outs, and more, bring the necessary elements of your studio's workflow at your fingertips. Install the rack unit in your 19" rack and perch the Remote Pendant proudly on your desk surface or console, with wireless operation keeping things nice and tidy at your workstation.

MANUFACTURER'S DESCRIPTION:

Shadow Hills took the long road, cutting no corners and sparing no expense to make the Oculus, the finest monitor console ever made. Drawing from years of experience creating some of the most coveted mastering compressors and summing mixers, Shadow Hills designed the Oculus with an utter devotion to audio integrity. The Remote Pendant wirelessly controls the esoteric architecture and mastering-grade topologies of the Oculus. This intuitive tactile interface is machined from a solid piece of aluminum, uniting technical innovation with sonic purity to create the ultimate reference monitor controller.

Features
  • Wireless Remote Pendant
  • Mastering-grade, fully-discrete passive volume attenuators for left and right monitors and subwoofer control
  • Five selectable fully balanced input sources
  • Class A active buffer for unbalanced source
  • Three selectable stereo speaker outputs
  • Adjustable speaker trims for equalizing sound pressure levels between monitors
  • Dedicated subwoofer output with trim-able level for each speaker selection
  • Large left and right VU meters
  • Connection for external VU meters and oscilloscope
  • Two Class A audiophile headphone amplifiers
  • Left, right and subwoofer mutes
  • Mono/Stereo selector collapses signals to mono
  • Complete large format console type talkback matrix with internal and external microphones, Class A microphone preamp and remote switching
  • Cue-follow for switching between external cue signals and the current input source selection
  • Auto-cue automatically engages talkback when the "tape" stops rolling
  • Internal Power Supply
Specifications
Minimum Frequency Response
1Hz – 100kHz @ -0.1dB
THD+N
0.001%
IMD
<0.001%
Crosstalk Rejection
>97%; >-100dBu
Passive Output Headroom
Infinite
Class-A Output Headroom
+28dBu
Minimum Frequency Response
Passive: 1Hz – 100kHz @ -0.1dB
THD+N
0.02%
Crosstalk Rejection
>97%; >-102dBu
