- 44.1k Hz to 192k Hz, 24 bit, 2 channel DAC
|
- Proprietary custom design BOPA1, all discrete op-amps
|
|
|
- Zero capacitor signal path
|
- Audiophile quality 6 position attenuator with standard headroom settings
|
- High definition metering with simultaneous RMS and peak indication
|
- Dante, 2 AES, SPDIF and Toslink input
|
- BNC word clock input with two outputs of extremely low jitter clock
|
- Frequency response at 48kHz sample rate is 10Hz to 22kHz, +/- 0.1dB
|
- Frequency response at 96kHz sample rate is 10Hz to 30kHz, +/- 0.1dB, -0.3 dB @ 40kHz
|
- Frequency response at 192kHz sample rate is 10Hz to 30kHz, +/- 0.1dB, -1.5 dB @ 90kHz
|
|
- -96dB THD+N, full scale output = +22dBU
|
- Rugged, Made in USA design
|
