Audio circuit type | Passive, transformer based
|
Transformer
| Jensen JT-DBE
|
Number of channels
| Single channel (mono)
|
Frequency response
| 20Hz ~ 20KHz (± 0.2dB)
|
Dynamic range
| 135dB
|
Maximum Input
| +21dB @ 20Hz ~ 20kHz
|
Features
| Input pad, Mono Sum, 180° polarity reverse, Ground lift, Speaker filter
|
Input Impedance
| 140k Ohms, unbalanced
|
Output Impedance
| 150 Ohms, balanced
|
Size (L x W x D)
| 5" x 3.3" x 1.8" (127mm x 84.1mm x 45.5mm)
|
Weight
| 1.92 lbs (870.9 grams)
|
Power
| Passive, no power required
|
Conditions
| For use in dry locations only between 5°C and 40°C
|
Warranty
| Radial 3-year, transferable
|
